Auravea Healthcare Pharmatech LLP
Instruments Portfolio
A complete instrument portfolio for pharmaceutical development, in-process control and quality assurance — from sterile filter integrity analyzers through to precision weighing.
Category 01
Next-generation integrity test systems built on Mass Flow Controller technology, combining measurement accuracy with 21 CFR Part 11 records and AI-assisted data management.
M19 FIA Series
FlagshipHigh-precision gas flow and pressure measurement across sterilizing-grade filters. Mass Flow Controller technology reduces test durations by 75% compared with legacy testers, and the 15-inch touchscreen puts recipe, result and audit trail on one screen.
Flow 0.01–1000 ml/min · Pressure accuracy ±0.1% · 15" colour touchscreen
Capability differs by model — check the row you depend on before specifying.
Scroll to compare →
Category 02
Instruments for R&D, in-process control and quality control — hardness, thickness, weight, diameter, disintegration and friability, on the bench or beside the press.
UTS 4.3
NewAutomatic testing of hardness, thickness, length, diameter and weight under one touch-driven software workflow. Available in laboratory and in-process control versions.
Hardness · thickness · length · diameter · weight · touch software
CIW 7.2 / CIW 7.3
Automatic weighing for tablets and capsules, with optional thickness measurement. Supplied in laboratory and in-process control configurations.
Models CIW 7.2 / CIW 7.3
Tablets & capsules · weight + optional thickness
UTS-S20
A dust-proof testing system with OEB 3 containment for handling active compounds. Measures weight, thickness, length and diameter, and hardness, with width available as an option.
Weight · thickness · length/diameter · hardness (width optional)
UTS-IP65i
Built for OEB 5 containment with an IP65-rated enclosure and wash-in-place cleaning, for potent compounds that cannot leave the containment envelope.
OEB 5 · IP65 rated · wash-in-place cleaning
HC7
Bench hardness testing with optional length, diameter and thickness measurement, available in three variants to match the depth of testing required.
Variants P3 / P4 / P5
Hardness + optional length/diameter & thickness
AE-1i / AE-2i
Friability and abrasion testing with one or two drum axes. An optional printer and balance allow weight loss to be calculated automatically at the end of the run.
Models AE-1i (1 axis) / AE-2i (2 axes)
1 or 2 drum axes · optional printer & balance for automatic weight-loss calculation
DISIevo
NewBathless induction heating removes the water bath entirely. Modular to four stations, with real-time monitoring of remaining tablet height, magnetic basket coupling and 21 CFR Part 11 records.
Induction heating · modular to 4 stations · real-time remaining-tablet-height monitoring
Single Punch Tablet Press
A GMP-built single punch press for development and small-batch production across a wide range of tablet diameters.
2–22 mm diameters · up to 50 kN · up to 3,600 tablets/hour
Category 03
USP, ChP, EP and JP compliant dissolution systems with a patented flow-path design, smart cloud connectivity and automatic performance monitoring.
DS-806 / DS-1206
Eight- and twelve-channel dissolution testers for manual sampling. Both meet Prednisone PQ mechanical standards, with a mobile temperature probe that records automatically.
Models DS-806 (8 ch) / DS-1206 (12 ch)
8/12 channels · manual sampling · automatic temperature recording
DS-806AT / DS-1206AT
Automatic sampling on a patented flow path, with two-stage online filtration through a 0.45 µm needle filter. Samples collect to tubes or directly into pre-filled vials.
Models DS-806AT (8 ch) / DS-1206AT (12 ch)
Patented flow path · 0.45 µm needle filter · collection to tubes or pre-filled vials
DS-7CP / DS-7SAT
Flow-through cell testing in open and closed loop. A ceramic piston pump delivers a verifiable sinusoidal waveform, with temperature and pressure recorded per channel.
Models DS-7CP / DS-7SAT
Verifiable sinusoidal waveform · per-channel temperature & pressure recording
DS-BIOAT
Reciprocating cylinder testing on a fixed-stroke rod and balanced platform. An optional 1 L vessel switches quickly to a 3×3 large-vessel configuration.
Balanced platform · quick switch to 3×3 large-vessel mode
TD-12AT
Twelve-channel transdermal diffusion testing with two-stage filtration at 0.45 µm and automatic collection into vials.
12 channels · two-stage filtration 0.45 µm · automatic vial collection
DGU-900
Inline degassing of dissolution media at up to 900 mL/min, with heating from room temperature to 45 °C and dissolved oxygen brought down to 2–3 ppm.
Up to 900 mL/min · 2–3 ppm dissolved O₂ · volume accuracy ≤1%
Category 04
German-engineered water purification delivering ASTM Type I, II and III water, with 21 CFR Part 11 records available across the range.
BerryPure Mini
A compact ultrapure system with continuous recirculation, a preheated UV lamp and onboard TOC monitoring — programmable dispensing from a single millilitre to fifty litres.
Flow to 1.7 L/min · programmable dispensing 1 mL–50 L · continuous recirculation
BerryPure UP Class
An enhanced ultrapure platform with a 7-inch touchscreen and RFID-monitored consumables, so cartridge status is tracked rather than estimated.
Models UP / UP+UF / UP+UV / UP+UV+UF
Flow to 2.1 L/min · RFID-monitored consumables
BerryPure SGK Ultra
Dispensing takes place under an argon blanket, which delivers water measurably better than conventionally filled systems — the manufacturer reports a 70% improvement in quality against conventional dispensing.
TOC, conductivity & temperature monitoring · 0.01–50 L dosing
BerryPure Mini RO+EDI
Runs directly from tap water to produce Type II water below 1 µS/cm, with a five-inch touchscreen and 21 CFR Part 11 records.
RO 12/24/36 L/h · RO+EDI 10/20/30 L/h · <1 µS/cm · 5" touchscreen
BerryPure Combi-Class
UP-Class and ROEDI technologies combined in one cabinet, delivering all three water types with multi-point dispensing from a single installation.
180–480 L/day · multi-point dispensing · 7" touchscreen
BerryPure Compact Class
A central system feeding a multi-floor ring line with UV disinfection. Pulsation flushing extends membrane life, with storage tanks up to 5000 L.
50–1000 L/h · tanks to 5000 L · pulsation flush extends RO life
Category 05
A GLP/GMP analytical range carrying 21 CFR Part 11 audit trails and electronic signatures across every instrument.
Smart-M Series
HD video recording at nine times magnification captures the melt for later review, with four samples measured in a single run.
Models M30 – M130
RT–420 °C · 4 samples · accuracy ±0.2 °C · 9× magnification
Smart-P Series
LED source at 589.3 nm with Peltier temperature control, measuring rotation, specific curl, concentration and sugar on a 10.4-inch touchscreen.
Models P610 / P630 / P910 / P930
LED 589.3 nm · rotation / specific curl / concentration / sugar · 10.4" touch
Smart-R Series
A linear CCD detector reading against a sapphire prism, with Peltier control across a wide working temperature range.
Models R200 – R600
nD 1.30000–1.70000 · Brix 0–100% · accuracy ±0.00001 nD
Smart-D Series
U-tube oscillation measurement with HD bubble detection, so an entrapped bubble is caught rather than silently biasing the result.
Models D50 / D70 / D90
0–3 g/cm³ · ±0.00001 g/cm³ · Peltier 5–85 °C · ASTM D1250/D1475/D4052
YK-T Series
Acid-base, REDOX, precipitation and complexometric titration with a rotary sampler and a PTFE valve block for aggressive reagents.
Models T6 – T9
16/18/20-station sampler · burette accuracy 0.003 mm
YK-DSC Series
Dual-thermocouple thermal analysis to 1400 °C with gas mass-flow control, operated from an eight-inch touchscreen.
RT–1400 °C · calorimetry accuracy 0.10% · 0.001 mW · 8" touch
YKD Series
One-button automatic determination with HD video capture, running two samples per batch across a wide programmable ramp.
Models YKD50 / Smart-YKD50 / YKD70
RT–400 °C · ramp 0.1–20 °C/min · 2 samples per batch
YKX-5 / YKX-5 Plus
Capillary melting point determination with 200× digital magnification and automatic fan cooling between runs.
Models YKX-5 / YKX-5 Plus
RT–400 °C · 3 samples · ramp 0.1–10 °C/min · auto fan cooling
Category 06
GMP laboratory furniture and safety equipment for handling, mixing and filtration.
StellaAir®
Filtration through HEPA and activated carbon means no external exhaust duct is required, so the hood can be sited where the work is rather than where the ductwork allows.
900 / 1200 / 1500 mm widths · face velocity 0.6 m/s · LCD control panel
Overhead Shaker
Heavy-duty mixing for large volumes, in stainless steel construction with attachments for a range of bottle and flask formats.
SS construction · multiple bottle & flask attachments
Ion Bench
A weighing enclosure for potent compounds with a built-in ionizer to settle static, integrated filtration and a height-adjustable surface. Mounted on castors.
Height-adjustable weighing surface · castor-mounted
Filter Table
Multi-position simultaneous filtration in stainless steel, with adjustable clamps that accept standard housings and Nutsche filters.
Adjustable clamps · standard housings & Nutsche compatible
Category 07
Precision analytical weighing for the laboratory bench.
DJ Series
A precision balance with a 4.4-inch LCD, anti-overload protection to 50 kg and RS232 output for thermal printers. Stabilises in a second or less and runs a full day on battery.
300 g–1200 g capacity · 0.01 g readability · ≤1 s stabilisation · anti-overload to 50 kg
Category 08
Weighing indicators and compact scales for industrial and laboratory use.
K1 / K2 / K3 Series
K1 offers a large-digit LCD; K2 adds Bluetooth and anti-vibration filtering; K3 is an LED indicator with limit alarms, and K3i adds a dual-channel fast refresh.
Models K1 / K2 / K3 / K3i
RS232 output · 24 h battery · anti-vibration filtering
FBS
A carat scale with German sensors behind a flip-cover windshield, reading in six units for gem and precious-metal work.
50–100 g capacity at 0.001 g · g / oz / ozt / dwt / gn / ct · backlit LCD
DM3
A stainless-steel-plate scale reading in six units, sized for light laboratory and formulation work.
200 g–3 kg · 0.01 g · g / oz / gn / ct / dwt / tola · 60 s auto-off
ES / QS / Notebook
Pocket-format scales with overturn and overload protection and a stainless steel pan, for sampling and spot checks away from the bench.
Models ES / QS / Notebook
20–500 g capacity · to 0.001 g · 60 s auto-off
Common questions
Three questions we are asked on almost every instrument enquiry.
Yes. Installation, operational and performance qualification documentation is supplied across the instrument range, including every model in the FIA-100 filter integrity series. The documents are prepared for the specific instrument and configuration you receive, so they can go straight into your validation file.
The analytical range carries 21 CFR Part 11 audit trails and electronic signatures throughout, as do the dissolution systems, the DISIevo disintegration tester and the M19 FIA analyzer. Within the FIA-100 series, Part 11 records are available on the FIA-100A and FIA-100S but not on the base FIA-100 — the comparison table on this page sets out exactly which model carries which capability.
Yes. Our team handles installation and commissioning and works through the qualification protocols with your validation group. Tell us the instrument, the site and your intended qualification approach, and we will scope the visit before anything ships.
Our team will match the right model to your lab and regulatory needs.
